Revoria Press™ PC1120

Description

High-Resolution Digital Toner Press

The first in a long line of digital toner presses, the Revoria Press™ PC1120 delivers unrivaled quality and performance. This system features a standout print engine, printing in full color with resolutions up to 2400 x 2400 dpi. It prints at 120 pages per minute and is compatible with a wide array of paper stocks and sizes, providing the freedom to bring your imagination to life.

The Revoria Press™ revolutionizes the digital toner press world. Its configurable layout provides unparalleled flexibility, allowing you to create a printing system that fits seamlessly within your application. Count on its innovative print server to strengthen your productivity while enhancing quality to streamline your operations, from pre-printing setup to post-printing finishing.

More About the Revoria PC1120

Quality and efficiency reach perfect symmetry within the Revoria Press™ PC 1120. Its state-of-the-art Vertical Cavity Surface Emitting Laser draws images simultaneously with multiple laser beams. This high-speed printing press has a minimum of 2000 sheet capacities, complete with an inline sensor allowing for quick setting adjustments to get your products just right. Watch the Revoria Press™ PC1120 exceed your expectations and construct results your customers will value.

6-Color Print Engine Brings Unrivaled Expressive Power to Digital Printing

Superior productivity with high-speed printing of 120 ppm even when printing in 6 Colors
High-definition expression with high-output resolution at 2400 x 2400 dpi
High-performance print server that maximizes print engine productivity
Supports a broad range of stocks: 52 gsm lightweight paper, 400 gsm heavyweight paper, minimum 98 x 148 mm and up to 330 x 1200 mm.
Various feeding and finishing options to streamline workflow from print to post-press.
This high-speed printing press has a minimum of 2000 sheet capacities, complete with an inline sensor allowing for quick setting adjustments to get your products just right.

10 colors, 6 stations, unlimited potential

Unleash your creative power

The Revoria Press PC1120 features an advanced print engine with 10 colors, including gold, silver, white, pink & clear, easily configurable in six before and after CMYK stations. With industry leading print quality, incredible media & finishing versatility, and the largest colour gamut, it is no surprise this award-winning press is taking the market by storm.

The Revoria Press™ PC1120 is Different

The Revoria Press™ will quickly become your business’s centerpiece, delivering nothing short of what you’d expect from a company with an extensive and rich history like Fujifilm. Our innovative technologies drive this system forward, including AI image corrections and inline features for full-bleed, trimming, creasing and folding products. You’ll roll through projects with minimal setbacks, little maintenance and reduced downtime — the way every project should be.

Quality and Productivity

Produce stunning photograph reproductions with uniform densities and sharp lines thanks to the EA-Eco toner, known for its tiny particle sizes. The PC1120 is also built with two specialty toner stations to use Clear, Gold, Silver, White, or Pink colors, creating vibrant color expressions. An internal scanner automatically inspects pages for defects such as dots, stains, pinholes and streaks, providing the peace of mind you deserve in high-quality results.

Image Processing

Fujifilm’s dedicated print server offers high-resolution and intuitive processing, streamlining your operations to meet every deadline. It features a professional color management system supporting various CMYK color profiles, including Fogra, SWOP and GRAcoL.

RIP processing and our Micro Accurate Control Screen technology with customizable screens create high-quality, smooth screen images for accurate renderings of print products. Unique enhancement solutions provide easy adjustments to jagged edges, blurred text and more.

Versatility

The PC1120 supports countless paper weights and sizes to operate successfully within various applications. This system accepts a minimum length of 3.8″ x 5.8″, stretching up to 12.9″ x 47.2″ and adjusting to meet the demands of lightweight and heavyweight stocks from 52 gsm to 400 gsm. Its air suction feeder and static eliminator reduce paper handling issues, ensuring each page is handled carefully and effectively fed through the system, regardless of texture or coating.

Flexible Feeding and Finishing Options

The possibilities are endless with the Revoria Press™ PC1120. Its modular design allows for a versatile configuration to fit the specifications of various projects and jobs. Additional units and third-party finishes are available to handle all printing and booklet-making needs, including stapling, folding and hole punching. Create the ideal inline finishing system to streamline your process and exceed all expectations.

Overview

6-color print engine brings unrivaled expressive power to digital printing

Superior productivity with high-speed printing of 120 ppm even when printing in 6 Colors
High-definition expression with high-output resolution at 2400 x 2400 dpi
High-performance print server that maximizes print engine productivity
Supports a broad range of stocks: 52 gsm lightweight paper, 400 gsm heavyweight paper, minimum 98 x 148 mm and up to 330 x 1200 mm.
Various feeding and finishing options to streamline workflow from print to post-press.

Features

Quality & Productivity ― Achieves both image quality and productivity at a high level.

1 pass 6-color print engine

In addition to CMYK toner, the press can load a maximum of two Specialty toner stations. For Specialty toner, choices of Clear^*1, Gold, Silver, White^*2 and Pink toners are available. By overlaying CMYK on Silver or Gold, you can print various brilliant metallic colors. The rich color expressions created by the 6-color print engine can expand your business.

*1 Clear toner can only be used for Overlay.
*2 White toner is avilable only in selected countries.

Diagram of specialty toner types with overlay and underlay

High resolution printing of 2,400 × 2,400 dpi

The heart of the printer, ROS^*1, uses VCSEL^*2 as a light source. It enables printing at 2,400 × 2,400 dpi high resolution by drawing images simultaneously with multiple laser beams.

*1 Raster Output Scanner
*2 Vertical Cavity Surface Emitting Laser

Super EA^*-Eco toner for high image quality

Super EA-Eco toner with extremely small particle size allows smooth reproduction of gradations in photographs, uniform density and sharper fine lines and text. It also produces easy-to-read printed text with less glare.

* EA: Emulsion Aggregation

Easy and quick adjustment

The in-line sensor is built into the printer body, allowing easy and quick calibration. It also has an automatic adjustment function that allows you to adjust^* multiple settings at once. It minimizes the effort required for maintenance and downtime.

* Batch adjustment of the following can be performed: Auto Alignment Adjustment, Adjust Image Transfer, Calibration, Density Uniformity Adjustment

Image Processing ― Print server with high resolution and fast processing

Image data processing maximising print engine performance

High quality image data can be generated with RIP processing of 1,200 x 1,200 dpi and 10 bit (1,024 gradation levels) on the Print Server. In addition, high resolution and smooth screen image of 2,400 x 2,400 dpi can be generated on the device with our unique HQ digital screen technology (MACS^*) employed. These data processing technologies can generate high image quality brought from the maximisation of the print engine performance.

* Micro Accurate Control Screen.

Professional color management system

Supports various CMYK color standards such as Fogra, SWOP and GRACoL

Calibration for G7 standard

G7® calibration achieves consistent gray balance and neutral tonality across different printing processes, substrates, and printing conditions.

Note: A standard that is widely adopted in the printing industry to ensure color consistency and quality across various printing technologies and platforms.

Image Enhancement in a more beautiful way

Higher image quality has been implemented with “Edge Enhancement” that fixes jaggedness on the edge of thin line and text outline and “Adjust Invert Text/Line Weight” that fixes thickened / blurred text.

Note: Default setting: OFF

Selecting different screens for individual objects for optimum image quality

You can select the suitable screen for each object such as a text and photo. The FM screen is effective for moire. Granular roughness that tends to occur on FM screens is suppressed by the dot arrangement suitable for the electrophotography profile, realising a smooth image quality.

Make skin texture beautiful

Print sample "Girl in pink clothes and hat"

Equipped with a function to brighten the image using fluorescent Pink toner. By separating into CMYK + Pink, skin tones can be brighter, and the texture of the skin can be reproduced smoothly and beautifully.

Note: You can choose 3 levels of effect. Since the pink layer is generated from magenta, it affects the images containing magenta.

AI-based photo quality optimisation*

AI (Artificial Intelligence) automatically determines the scene for each photographic image on the page and corrects the image appropriately for each of them. low quality images, such as poor contrast and brightness, can be automatically corrected.

* Applies to RGB type images.

Versatility ― A wider range of media types and finishes

Supporting a wide range of paper weights from lightweight paper of 52 gsm to heavyweight paper of 400 gsm

Paper sizes ranging from A6 to 330 × 488 mm are available. Fullbleed printing on SRA3 (320 × 450 mm) is also possible and it is useful to create brochures or leaflets that need to have bleed.

Supports banner sheet of Maximum 1,200 mm

You can print up to 330 x 1,200 mm banner sheets for simplex printing^*. Widen the scope of new printing application such as powerful panoramic posters.

Note: Please contact our sales representative for paper feeder or output module that is required for Banner sheet printing

* Up to 330 x 729 mm for automatic duplex printing.

Eliminate static electricity on Film and Metallic media

Film and metallic medias are easily charged by static electricity when printing, and the printed medias may stick together. However, the in-line static eliminator module^* makes it easy to stack and align these media.

* Optional “Static Eliminator D1”.

Various in-line finishing^*

You can create a variety of finished products with full bleed, trimming, crease and folding options.

* Optional

“Air Suction Feeder^*” with enhanced paper handling capabilities

Shuttle head draws up the paper strongly using air, it delivers each sheet securely. This improves paper feeding performance for low quality, textured and coated
stocks.

* Optional
